Simple, Super Low Friction Linear Motion Conveyance System
December 16th, 2016
Editor Transporter 2 Roller Block and Rail system from LM76
The Transporter 2 Roller Block and Rail system from LM76 is just that…practical. A black anodized aluminum carriage plate which features 4 plastic wheels pressed over ABEC 1 roller bearings. Transporter’s rail features a ceramic coated aluminum extrusion which offers a hard, extremely durable running surface. Transporter 2 offers 2 carriage plate designs: Option 1 is a standard block with 4) 10-32 mounting holes. Option 2 is a longer and more narrow block with 4) 10-32 mounting holes and a hand lock assembly. This low friction, maintenance free system is superb for sliding doors, manual assembly lines, camera motion and any other applications where low friction motion is required. Transporter is not for high loads or moment loading or for applications which require high speed, critical accuracy or wash down.
|
||||||
|
|
||||||
 |
||||||
 |
-
Machine Tool Sliding Doors
-
Postal Equipment Linear Transporters
-
Monitor Stands
-
Hand/Manual Assembly
Lines -
Lab Equipment
-
Syringe Docking/Filling
Systems -
Cable&Hose Management System Guidance Trolleys
(i.e. igus/A&A Gore-Tite) -
Aerial Pneumatic Tool
Festoon Followers -
Table Top Conveyance –
Arts and Crafts -
Positioning for Measurement
Components -
Cable Reel Followers
-
Furniture Sliders
-
Closet Door Sliders
-
Small Appliance Sliders
-
Rack Shelf Sliders
-
Pulley Dancers
-
Moveable Armrest Sliders for Wheelchairs
-
Small Camera Slider
-
Wall Sliders for Monitors
and Flat Panel Displays
|
|
Carriage Block P/N |
| TPS ( Standard Block) |
| TPL Long and Narrow Block with Hand |
|
TPS Standard Block |
|
|
|
Dimensions |
| A ±.010 |
B ±.010 |
C ±010 |
D | E |
| 1.000 | 0.620 | 0.125 | 0.940 | 0.500 |
| F | Standard Rail Lengths | H Screw Inch |
H1 | H2 | H3 | ||||
| 1.500 | 7,13,19,25,31 | # 10 | .375 | .220 | .206 | ||||
| NOTE: Rails are available up to 10 feet long. We will cut special lengths and provide special hole locations if provided a print. Please call Christine Carlson 1-800-513-3163 for further information or email sales@LM76.com |
|||||||||
Part Number Example: LR3-36 1 LR3 Rail – 36″ Long |
|||||||||
About LM76
Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman PTFE Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.
For all of the LM76 Catalogs go to:
http://lm76.com/PDF%20Catalogs.htm
For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone: 413-525-4166, Fax: 413-525-3735 or E-Mail:mquinn@lm76.com or visit the website at http://www.lm76.com
 |
 |
Wide, High Accuracy, Low Cost Linear Motion Systems Resist – Roll, Pitch, and Yaw!
July 6th, 2016 Editor
 |
Longmeadow, MA – Linear Motion Control –The low cost, wide, stable platforms of the SAIBO SB-LGC Linear Motion Systems are available exclusively from LM76 in two sizes to meet load requirements up to 6000 N. (1349 lbs). These wide, low profile linear motion systems feature: Low noise, smooth travel, high speed to 10 m/s (120 ft/s), high acceleration to 50 m/s (150 ft/s), low weight, high linear accuracy, sealed radial low friction bearings, low cost, and because of their wide profile they have high moment (Roll, Pitch, and Yaw) load capacities. Additionally they are easy to install, in any orientation, into new and existing applications. SB-LGC maintenance free linear motion systems have sealed for life rollers, RC60 hardened shafts, and are available in lengths to 6000 mm (263 in.)
SAIBO SB-LGC Linear Motion Platform and Rail System have an adjustable preload system to control the required level of precision needed for most applications. Capable of loads to 6000 N (1349 lbs), the very stable LGC platforms have four drilled and tapped holes for mounting tooling, cameras, test equipment, etc. For use in: Robotics, assembly, photography, pick-and-place, sorting, packaging, manufacturing, sampling, laser cutting, wafer handling, and other precision applications.
LM76, the exclusive US distributor of SAIBO linear motion components, manufacturers a broad variety of FDA & USDA compliant bearings and shafting, in inch sizes of .25 inches to 1.5 inches, and a FDA & USDA compliant profile rail and slide system that can easily be integrated into new and existing applications. The bearing options include: Self-lubricating FDA & USDA compliant Teflon® composite bearings in a 304 stainless steel shell, and lower cost bearings with a ceramic coated shell and FDA & USDA compliant liner. Bearings are available in closed and open configurations, and are drop-in replacements for all inch sized linear ball bearings.
About LM76
Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman PTFE Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.
For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone: 413-525-4166, Fax: 413-525-3735 or E-Mail:mquinn@lm76.com or visit the website at http://www.lm76.com
|
 |
 |
Linear Motion – Tiger Linear Bearings, Great for High Loads!
March 20th, 2015 Editor
|
E. Longmeadow, MA – Linear Motion – Tiger Bearings from LM76 are a tough maintenance-free option to traditional PTFE lined or injection molded plastic linear bearings. Available as 3/4 inch and 1 inch closed bearings, these are the ideal bearings for high load applications up to 35,000 lbs. such as: Backhoes, front end loaders, marine davits/sheaves, valve stem bushings, hitches, hydraulic cylinder pivots, graders, and mining equipment.
Tiger Bearings, developed by LM76 engineers, are multi-layered. These drop-in replacement bearings feature a standard diameter ceramic coated aluminum outer shell. The innermost layer consists of a synthetic fiber/PTFE layer. The middle layer consists of epoxy-coated high-angle glass filaments, and the outer layer is of epoxy-coated low-angle glass filaments. It is this multilayered design that withstands the crushing shock loads, environmental contamination, the simultaneous rotating and twisting motion, shaft misalignment, corrosive chemicals and high and low temperatures found in construction and marine environments.
The electrically insulated, layered Tiger Bearings are self-lubricating (coefficient of friction is just .02 to.25), operate in temperatures of -300O F to +300O F, and have very low water absorption (<.05%). The layers of high angle and low angle epoxy coated glass filaments stabilize the bearings preventing “Creep” or “Cold Flow” under high pressure typical of standard PTFE bearings under high loads.
About LM76
Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman PTFE Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.
For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone: , Fax: 413-525-3735 or E-Mail: mquinn@lm76.com or visit the website at http://www.lm76.com
|
|
Linear Motion – We Want To Get To Know You Better!
December 8th, 2014 Editor | We want to get to know you better so we can better serve your needs. It goes without saying that OEM Purchasing has a different set of needs than Design Engineering. Thus we have broken our customer base into 4 categories: OEM Purchasing, Design/Mechanical Engineering, Bearing Distribution and MRO Maintenance. Beginning in January 2015, we will create blog pages and RSS Feeds tailored to each group. Your feedback is critical in making this program a success:Tell us what you need
Tell us what you expect and let us do the rest. |
|||
 OEM Purchasing Fill-out our survey and get a free copy of Best Linear Buying Practices |
|||
 Design/Manufacturing Engineering Fill-out our survey and get a copy of our latest engineering solution white paper |
|||
 Bearing Distributors Fill-out our survey and get a copy of our 2014 Distributor policy |
|||
 MRO Maintenance Fill-out our survey and get our MRO Policy |
|||
LM76 also manufacturers a broad variety of FDA & USDA compliant bearings and shafting, in inch sizes of .25 inches to 1.5 inches, and a FDA & USDA compliant profile rail and slide system that can easily be integrated into new and existing applications. The bearing options include: Self-lubricating FDA & USDA compliant Teflon® composite bearings in a 304 stainless steel shell, and lower cost bearings with a ceramic coated shell and FDA & USDA compliant liner. Bearings are available in closed and open configurations, and are drop-in replacements for all inch sized linear ball bearings.
Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman Teflon® Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.
For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone: , Fax: 413-525-3735 or E-Mail: mquinn@lm76.com or visit the website at http://www.lm76.com
|
|
|
Linear Motion – Low Cost, High Speed Linear Roller Blocks and Rail Systems!
September 17th, 2014 Editor
|
E. Longmeadow, MA – Linear Motion – LM76 is the exclusive distributor of SAIBO Linear Motion Systems in the US. SAIBO SB-LGA Roller Block and Rail Systems feature: Low noise, smooth travel, high speed to 10 m/s (120 ft/s), high acceleration to 50 m/s (150 ft/s), low weight, high accuracy, low friction, low cost, and easy installation into new and existing applications. SB-LGA systems are available in three sizes to meet load requirements up to 1200 N. (270 lbs) and lengths to 4000 mm (157 in.)
SAIBO SB-LGA Roller Block and Rail Systems have an adjustable preload system to control the required level of precision needed for most applications. For use in: Robotics, assembly, pick-and-place, sorting, packaging, manufacturing, sampling, laser cutting, wafer handling, and other precision applications. The rail systems are protected from debris, dust, chips, and contaminates by oil filled felt pads held in place by spring loaded plastic end caps. The felt wiper pads also deliver lubrication to the guide and rollers. The wipers are easily relubricated through convenient oil ports in the end caps.
LM76, the exclusive US distributor of SAIBO linear motion components, also manufacturers a broad variety of FDA & USDA compliant bearings and shafting, in inch sizes of .25 inches to 1.5 inches, and a FDA & USDA compliant profile rail and slide system that can easily be integrated into new and existing applications. The bearing options include: Self-lubricating FDA & USDA compliant Teflon® composite bearings in a 304 stainless steel shell, and lower cost bearings with a ceramic coated shell and FDA & USDA compliant liner. Bearings are available in closed and open configurations, and are drop-in replacements for all inch sized linear ball bearings.
Founded in 1976, LM76 has been a leading designer/manufacturer of linear bearings, slides and linear motion systems. LM76 is renowned for its industry leading Minuteman Teflon® Composite linear bearings. LM76 is a leading supplier of precision linear shafting: RC60, 300 Series Stainless Steel, and ceramic-coated aluminum shafting. LM76 also offers several FDA/USDA compliant linear bearings and slides for the food processing, pharmaceutical, medical, and packaging industries.
For additional information contact Mike Quinn at: LM76, 140 Industrial Dr., E. Longmeadow, MA 01028; Telephone:
413-525-4166, Fax: 413-525-3735 or E-Mail: mquinn@lm76.com or visit the website at http://www.lm76.com
|
|
|
Linear Bearing Engineers Design Camera Sliders for the Pro and Beginner!
December 12th, 2013 Editor
 |
Designed by Linear Bearing Engineers Camera Sliders for the Beginner and the PRO
|
